• ADJUSTABLE & FULLY REVERSIBLE - 12 STAGES
  • BOTH PARTS OF THE HITCH ARE REVERSIBLE
  • 6 STAGES OF DROP - 80MM/110MM/130MM/140MM/160MM/190MM
  • 6 STAGES OF RISE - 50MM/80MM/105MM/110MM/135MM/165MM
  • 10MM DUAL SUPPORT GUSSETS FOR ADDED STRENGTH
  • SUITS MM PAJERO SPORT & FORD RANGER SHALLOW RECEIVER COMPATIBLE PIN HOLE ) (40mm from end of shank))
  • USES 12.9 GRADE HIGH TENSILE 16MM BOLTS (TORQUE to 189Nm)
  • 25MM X 75MM HEAVY DUTY BALL PLATFORM.
  • MATTE BLACK SEAGUARD FINISH
  • 5.75mm THICK STEEL SHANK
  • ROBOTIC WELDED FOR CONSISTENT QUALITY
  • CNC MACHINED FOR MAXIMUM ACCURACY
  • FITS 2" X 2" TOWBAR RECEIVERS
  • ADR62 COMPLIANT
  • ORIGINAL DESIGN BY MISTER HITCHES AUSTRALIA

GROSS TRAILER WEIGHT: 4000KG

TONGUE WEIGHT: 400KG

BALL HOLE SIZE: 7/8"

MAX DROP: 190MM

MAX RISE: 165MM

LENGTH: (MEASURED FROM CENTRE OF PIN HOLE TO CENTRE OF BALL HOLE) 252MM

PIN HOLE TO END OF SHANK 40MM

PIN HOLE TO GUSSET 60MM

SUITS STONE STOMPER UNDER BALL BRACKET & MOST COUPLINGS EG. D035

MEASUREMENTS ARE APPROX.

SKU MHABM-5XHDP
Brand Mister Hitches
