• ADJUSTABLE & REVERSIBLE - 16 STAGES OF ADJUSTMENT

  • 432MM (17") ADJUSTABLE VERTICAL TRAVEL

  • INCLUDES 2 x 5/8" 10,000KG DOUBLE SHEAR RATED HITCH PINS AND CLIPS

  • MATTE BLACK SEAGUARD POWDER COATED FINISH

  • NEW STRONGER 7MM THICK U SECTION BALL PLATFORM CHANNEL

  • 6.2MM SHANK WALL THICKNESS.

  • ROBOTIC WELDED FOR CONSISTENT QUALITY

  • CNC MACHINED FOR MAXIMUM ACCURACY

  • INCLUDES ANTI-RATTLE BOLT

  • FITS 2" X 2" TOWBAR RECEIVERS

  • COMPLIES WITH ADR TESTING REQUIREMENTS

GROSS TRAILER WEIGHT: 2722KG

TONGUE WEIGHT: 272KG

BALL HOLE SIZE: 7/8"

MAX DROP: 240MM

MAX RISE: 210MM

LENGTH: 305MM (MEASURED FROM CENTRE OF PIN HOLE TO CENTRE OF BALL HOLE)

SKU MHABM
Barcode # 2000000010328
Brand Mister Hitches
Shipping Weight 7.0000kg
